MikroTik PWR-LINE AP (EU plug) — PL7411-2nD

Manufacturer P/N: PL7411-2nD

Mikrotik PL7411-2nD network equipment. Architecture: MIPSBE; CPU: QCA9533; CPU core count: 1. Compare configuration and request a hardware quote.

Architecture: MIPSBE
CPU: QCA9533
CPU core count: 1
CPU nominal frequency: 650 MHz

Price on request

Pricing, availability, condition, included options and warranty are confirmed in your quotation.

Help choosing compatible hardwareWorldwide delivery

CONNECTIONS & COMPATIBILITY

Network connections and supported equipment

Check the protocol and port requirements of the equipment you intend to connect. Ethernet, Fibre Channel, InfiniBand and carrier interfaces are not interchangeable.

CONNECTS TOClients, servers or access links

PL7411-2nDNetwork Equipment

USED FORConnected network equipment

Connection and installation requirements

Port type, line rate, optics, reach and software license
Peer platform support, resiliency and management design

Storage connection examples ↗Servers & appliances ↗

Browse the product categories above for related equipment. Confirm compatibility with your full configuration before ordering.

Technical overview

Technical specifications

Use the complete part number when reviewing options and system requirements.

PL7411-2nD specifications
Manufacturer	Mikrotik
Manufacturer part number	PL7411-2nD
Product family	Data over Powerlines
Architecture	MIPSBE
CPU	QCA9533
CPU core count	1
CPU nominal frequency	650 MHz
PLC chipset	AR7420
Dimensions	50 x 68 x 33mm
RouterOS license	4
Operating System	RouterOS
Size of RAM	64 MB
Storage size	16 MB
Storage type	FLASH
Tested ambient temperature	-20°C to 60°C
AC input range	100-240
Frequency (Hz)	50-60
Max power consumption	7 W
Wireless 2.4 GHz Max data rate	300 Mbit/s
Wireless 2.4 GHz Number of chains	2
Wireless 2.4 GHz standards	802.11b/g/n
Antenna gain dBi for 2.4 GHz	1.5
Wireless 2.4 GHz chip model	QCA9533
Wireless 2.4 GHz generation	Wi-Fi 4
10/100 Ethernet ports	1

PRODUCT DETAILS

Features and applications

PL7411-2nD at a glance

MikroTik PWR-LINE AP (EU plug) — PL7411-2nD is a network equipment in the Data over Powerlines range. Use the model code when matching your deployment or replacement requirement.

Architecture: MIPSBE
CPU: QCA9533
CPU core count: 1

Legacy hardware sourcing

This model appears in the manufacturer’s archived product range. Ask for the offered condition, firmware requirements and support position. Archived status does not establish available stock or a guaranteed support end date.

Configuration and installation

Check installation dimensions, power requirements, interface compatibility and required accessories. Confirm whether the quoted item is a complete device or an individual component.

Confirm hardware revision and included items in the quotation. A firmware-dependent feature or licensed capability must be checked against the actual configuration.
