Model and quantity
Include the full model, manufacturer P/N, revision and quantity.
Mikrotik / IoT Network Device
MikroTik KNOT LR8G kit — RB924iR-2nD-BT5&BG770A&R11e-LR8G
Manufacturer P/N: RB924iR-2nD-BT5&BG770A&R11e-LR8G
Mikrotik RB924iR-2nD-BT5&BG770A&R11e-LR8G iot network device. Architecture: MIPSBE; CPU: QCA9531; CPU core count: 1. Compare configuration and request a hardware quote.
- Architecture
- MIPSBE
- CPU
- QCA9531
- CPU core count
- 1
- CPU nominal frequency
- 650 MHz
Price on request
Contact us to confirm availability. Final price, shipping and taxes are confirmed before payment.
Pricing, availability, condition, included options and warranty are confirmed in your quotation.
Help choosing compatible hardwareWorldwide delivery
CONNECTIONS & COMPATIBILITY
Network connections and supported equipment
Check the protocol and port requirements of the equipment you intend to connect. Ethernet, Fibre Channel, InfiniBand and carrier interfaces are not interchangeable.
CONNECTS TOClients, servers or access links
RB924iR-2nD-BT5&BG770A&R11e-LR8GIoT Network Device
USED FORConnected network equipment
Connection and installation requirements
- Port type, line rate, optics, reach and software license
- Peer platform support, resiliency and management design
Browse the product categories above for related equipment. Confirm compatibility with your full configuration before ordering.
Technical overview
Technical specifications
Use the complete part number when reviewing options and system requirements.
| Manufacturer | Mikrotik |
|---|---|
| Manufacturer part number | RB924iR-2nD-BT5&BG770A&R11e-LR8G |
| Product family | IoT products |
| Architecture | MIPSBE |
| CPU | QCA9531 |
| CPU core count | 1 |
| CPU nominal frequency | 650 MHz |
| Switch chip model | QCA9531 |
| RouterOS license | 4 |
| Operating System | RouterOS v7 |
| Size of RAM | 64 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| Tested ambient temperature | -40°C to 70°C |
| MicroUSB input Voltage | 5 V |
| Number of DC inputs | 3 (DC jack, PoE-IN, MicroUSB) |
| DC jack input Voltage | 12-57 V |
| Max power consumption | 23 W |
| Max power consumption without attachments | 6 W |
| PoE in | 802.3af/at |
| Cooling type | Passive |
| PoE in input Voltage | 18-57 V |
| PoE-out ports | Ether2 |
| PoE out | Passive PoE |
| Low voltage PoE-Out current limit | 650 mA |
| High voltage PoE-Out current limit | 450 mA |
| Total output power | 12 |
| Wireless 2.4 GHz Max data rate | 300 Mbit/s |
| Wireless 2.4 GHz Number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 1.5 |
| Wireless 2.4 GHz chip model | QCA9531 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
| 10/100 Ethernet ports | 2 |
| Number of SIM slots | 1 Smart card (Nano SIM) |
| MiniPCI-e slots | 1 |
| Serial console port | RS485 |
| Number of USB ports | 1 |
| USB slot type | microUSB type AB |
| Max USB current (A) | 1 |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| Bluetooth version | 5.2 |
| Bluetooth RF connector type | uUFL |
| GPS RF connector type | SMA |
| IP | 20 |
PRODUCT DETAILS
Features and applications
RB924iR-2nD-BT5&BG770A&R11e-LR8G at a glance
MikroTik KNOT LR8G kit — RB924iR-2nD-BT5&BG770A&R11e-LR8G is an iot network device in the IoT products range. Use the model code when matching your deployment or replacement requirement.
- Architecture: MIPSBE
- CPU: QCA9531
- CPU core count: 1
Configuration and installation
Check installation dimensions, power requirements, interface compatibility and required accessories. Confirm whether the quoted item is a complete device or an individual component.
Confirm hardware revision and included items in the quotation. A firmware-dependent feature or licensed capability must be checked against the actual configuration.
Related IoT products models
- MikroTik LtAP LR8G LTE6 kit — LtAP-2HnD&FG621-EA&LR8G — LtAP-2HnD&FG621-EA&LR8G
- MikroTik KNOT LR8 kit — RB924iR-2nD-BT5&BG77&R11e-LR8 — RB924iR-2nD-BT5&BG77&R11e-LR8
- MikroTik KNOT LR9G kit — RB924iR-2nD-BT5&BG770A&R11e-LR9G — RB924iR-2nD-BT5&BG770A&R11e-LR9G
- MikroTik KNOT LR9 kit — RB924iR-2nD-BT5&BG77&R11e-LR9 — RB924iR-2nD-BT5&BG77&R11e-LR9
- MikroTik wAP LR8G kit — RBwAPR-2nD&R11e-LR8G — RBwAPR-2nD&R11e-LR8G
- MikroTik wAP LR9G kit — RBwAPR-2nD&R11e-LR9G — RBwAPR-2nD&R11e-LR9G
- MikroTik wAP LR9 kit — RBwAPR-2nD&R11e-LR9 — RBwAPR-2nD&R11e-LR9
- MikroTik wAP LR2 kit — RBwAPR-2nD&R11e-LR2 — RBwAPR-2nD&R11e-LR2
Ordering questions
What should I include in an enquiry?
Send RB924iR-2nD-BT5&BG770A&R11e-LR8G with quantity, destination, required condition and any installation constraints. List power, optics or mounting accessories separately when required.
Are accessories and support included?
Inclusions depend on the exact ordering configuration. We confirm the supplied hardware, accessories and applicable commercial terms in writing.
