Mikrotik / Router Board

MikroTik RB435G

Manufacturer P/N: RB435G

Mikrotik RB435G router board. Architecture: MIPSBE; CPU: AR7161; CPU core count: 1. Compare configuration and request a hardware quote.

Architecture: MIPSBE
CPU: AR7161
CPU core count: 1
CPU nominal frequency: 680 MHz

Price on request

Pricing, availability, condition, included options and warranty are confirmed in your quotation.

Help choosing compatible hardwareWorldwide delivery

CONNECTIONS & COMPATIBILITY

Network connections and supported equipment

Check the protocol and port requirements of the equipment you intend to connect. Ethernet, Fibre Channel, InfiniBand and carrier interfaces are not interchangeable.

CONNECTS TOClients, servers or access links

RB435GRouter Board

USED FORConnected network equipment

Connection and installation requirements

Port type, line rate, optics, reach and software license
Peer platform support, resiliency and management design

Storage connection examples ↗Servers & appliances ↗

Browse the product categories above for related equipment. Confirm compatibility with your full configuration before ordering.

Technical overview

Technical specifications

Use the complete part number when reviewing options and system requirements.

RB435G specifications
Manufacturer	Mikrotik
Manufacturer part number	RB435G
Product family	RouterBOARD
Architecture	MIPSBE
CPU	AR7161
CPU core count	1
CPU nominal frequency	680 MHz
Switch chip model	AR8316-AK1E-R
Dimensions	105mm x 154mm
RouterOS license	5
Operating System	RouterOS
Size of RAM	256 MB
Storage size	64 MB
Storage type	NAND
Tested ambient temperature	-40°C .. +70°C tested
Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input Voltage	8-28 V
PoE in	Passive PoE
Cooling type	Passive
PoE in input Voltage	8-28 V
10/100/1000 Ethernet ports	3
Memory card type	microSD
Memory Cards	1
MiniPCI slots	5
Serial console port	RS232
Number of USB ports	2
USB slot type	USB type A
Max USB current (A)	1.5
Current Monitor	Yes
PCB temperature monitor	Yes
Voltage Monitor	Yes
Beeper	Yes

PRODUCT DETAILS

Features and applications

RB435G at a glance

MikroTik RB435G is a router board in the RouterBOARD range. Use the model code when matching your deployment or replacement requirement.

Architecture: MIPSBE
CPU: AR7161
CPU core count: 1

Legacy hardware sourcing

This model appears in the manufacturer’s archived product range. Ask for the offered condition, firmware requirements and support position. Archived status does not establish available stock or a guaranteed support end date.

Configuration and installation

Check installation dimensions, power requirements, interface compatibility and required accessories. Confirm whether the quoted item is a complete device or an individual component.

Confirm hardware revision and included items in the quotation. A firmware-dependent feature or licensed capability must be checked against the actual configuration.
