MikroTik RB912UAG-5HPnD product reference image
Product reference image

Mikrotik / Router Board

MikroTik RB912UAG-5HPnD

Manufacturer P/N: RB912UAG-5HPnD

Mikrotik RB912UAG-5HPnD router board. Architecture: MIPSBE; CPU: AR9342; CPU core count: 1. Compare configuration and request a hardware quote.

Architecture
MIPSBE
CPU
AR9342
CPU core count
1
CPU nominal frequency
600 MHz

Price on request

Contact us to confirm availability. Final price, shipping and taxes are confirmed before payment.

Place order request
Request a quote

Pricing, availability, condition, included options and warranty are confirmed in your quotation.

Help choosing compatible hardwareWorldwide delivery

CONNECTIONS & COMPATIBILITY

Network connections and supported equipment

Check the protocol and port requirements of the equipment you intend to connect. Ethernet, Fibre Channel, InfiniBand and carrier interfaces are not interchangeable.

CONNECTS TOClients, servers or access links
RB912UAG-5HPnDRouter Board
USED FORConnected network equipment
Connection and installation requirements
  • Port type, line rate, optics, reach and software license
  • Peer platform support, resiliency and management design
Storage connection examples ↗Servers & appliances ↗

Browse the product categories above for related equipment. Confirm compatibility with your full configuration before ordering.

Technical overview

Technical specifications

Use the complete part number when reviewing options and system requirements.

RB912UAG-5HPnD specifications
ManufacturerMikrotik
Manufacturer part numberRB912UAG-5HPnD
Product familyRouterBOARD
ArchitectureMIPSBE
CPUAR9342
CPU core count1
CPU nominal frequency600 MHz
Dimensions105x105mm
RouterOS license4
Operating SystemRouterOS
Size of RAM64 MB
Storage size128 MB
Storage typeNAND
Tested ambient temperature-40°C to 70°C
Number of DC inputs2 (DC jack, PoE-IN)
DC jack input Voltage8-30 V
Max power consumption12 W
PoE inPassive PoE
Cooling typePassive
PoE in input Voltage8-30 V
Wireless 5 GHz Max data rate300 Mbit/s
Wireless 5 GHz Number of chains2
Wireless 5 GHz standards802.11a/n
Wireless 5 GHz chip modelAR9342
Wireless 5 GHz generationWi-Fi 4
10/100/1000 Ethernet ports1
Number of SIM slots1 Modem (Mini SIM)
MiniPCI-e slots1
Number of USB ports1
USB Power ResetYes
USB slot typeUSB type A
Max USB current (A)1
PCB temperature monitorYes
Voltage MonitorYes
BeeperYes
IPIP00

PRODUCT DETAILS

Features and applications

RB912UAG-5HPnD at a glance

MikroTik RB912UAG-5HPnD is a router board in the RouterBOARD range. Use the model code when matching your deployment or replacement requirement.

  • Architecture: MIPSBE
  • CPU: AR9342
  • CPU core count: 1

Configuration and installation

Check installation dimensions, power requirements, interface compatibility and required accessories. Confirm whether the quoted item is a complete device or an individual component.

Confirm hardware revision and included items in the quotation. A firmware-dependent feature or licensed capability must be checked against the actual configuration.

Related RouterBOARD models

Ordering questions

What should I include in an enquiry?

Send RB912UAG-5HPnD with quantity, destination, required condition and any installation constraints. List power, optics or mounting accessories separately when required.

Are accessories and support included?

Inclusions depend on the exact ordering configuration. We confirm the supplied hardware, accessories and applicable commercial terms in writing.

Browse Mikrotik equipment · Network equipment · Request a matched quotation

Prepare your enquiry

Ordering and delivery

Model and quantity

Include the full model, manufacturer P/N, revision and quantity.

Your existing equipment

Tell us the host model, generation, installed configuration and required supporting hardware.

Delivery requirements

Specify condition, testing requirements, destination and requested delivery date.
