Model and quantity
Include the full model, manufacturer P/N, revision and quantity.
TP-Link / Enterprise Router
TP-Link DR3650v-4G
Manufacturer P/N: DR3650v-4G
TP-Link DR3650v-4G enterprise router. SIM Type: Dual-SIM Nano SIM Slot (4G+ Cat6); Cellular data rates: • Downlink: 300 Mbps; • Uplink: 50 Mbps; Access Control: • Source/Destination IP Based ACL Stateful ACL • IPv4/IPv6 ACL • National Based ACL • FQDN. Compare configuration and request a hardware quote.
- Documented hardware version
- V1.20; match the hardware revision before ordering
- SIM Type
- Dual-SIM Nano SIM Slot (4G+ Cat6)
- Cellular data rates
- • Downlink: 300 Mbps; • Uplink: 50 Mbps
- Access Control
- • Source/Destination IP Based ACL Stateful ACL • IPv4/IPv6 ACL • National Based ACL • FQDN
Price on request
Contact us to confirm availability. Final price, shipping and taxes are confirmed before payment.
Pricing, availability, condition, included options and warranty are confirmed in your quotation.
Help choosing compatible hardwareWorldwide delivery
CONNECTIONS & COMPATIBILITY
Network connections and supported equipment
Check the protocol and port requirements of the equipment you intend to connect. Ethernet, Fibre Channel, InfiniBand and carrier interfaces are not interchangeable.
CONNECTS TOClients, servers or access links
DR3650v-4GEnterprise Router
USED FORConnected network equipment
Connection and installation requirements
- Port type, line rate, optics, reach and software license
- Peer platform support, resiliency and management design
Browse the product categories above for related equipment. Confirm compatibility with your full configuration before ordering.
Technical overview
Technical specifications
Use the complete part number when reviewing options and system requirements.
| Manufacturer | TP-Link |
|---|---|
| Manufacturer part number | DR3650v-4G |
| Product family | Business enterprise routers |
| Documented hardware version | V1.20; match the hardware revision before ordering |
| SIM Type | Dual-SIM Nano SIM Slot (4G+ Cat6) |
| Cellular data rates | • Downlink: 300 Mbps; • Uplink: 50 Mbps |
| Access Control | • Source/Destination IP Based ACL Stateful ACL • IPv4/IPv6 ACL • National Based ACL • FQDN |
| DPI | • Deep Packet Inspection • Support 2421 type Applications |
| DNS Proxy | DNSSEC, DoH, DoT, and DNS Override |
| Attack Defense | • TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WAN |
| GRE | √ (Only in Standalone Mode) |
| SSL VPN | 50 Tunnels |
| WireGuard VPN | √ |
| SD-WAN | √ (Only in Controller Mode) |
| Button | Reset Button |
| Power Supply | 12V DC / 3.3A Power Adapter |
| Wi-Fi Frequency & Signal Rate | • 2.4 GHz: 574 Mbps • 5 GHz: 2402 Mbps (HE160) |
| Flash | 256 MB NAND |
| DRAM | 512 MB DDR4 |
| Dimensions ( W x D x H ) | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) (Antenna dimensions are not included) |
| Antenna | • Wi-Fi: 3× 5GHz 5dBi & 2.4GHz 3.5dBi dual-band detachable antennas • LTE: 2× 4.0dBi omnidirectional detachable antennas |
| Mounting | Desktop / Wall / Rack mount (Purchase Rackmount Kit-D226 Separately) |
| Max. Power Consumption | Power adapter not included: 28.482 W (Full load + USB) Power adapter included: 31.42 W (Full load + USB) |
| Concurrent Session | 150,000 |
| New Sessions /Second | 3,800 |
| NAT (Static IP) | • Upload: 937.2 Mbps • Download: 936.1Mbps |
| NAT(DHCP) | • Upload: 945.8 Mbps • Download: 940.6Mbps |
| NAT(PPPoE) | • Upload: 942.9 Mbps • Download: 942.9Mbps |
| NAT (L2TP) | • Upload: 837.4 Mbps • Download:881.5Mbps |
| NAT (PPTP) | • Upload: 803.0 Mbps • Download: 910.5 Mbps |
| 66 Byte Packet Forwarding Rate | 1,453,489 pps / 1,453,488 pps |
| 1,518 Byte Packet forwarding rate | 81,274 pps / 91,275 pps |
| IPsec VPN Throughput | • ESP-SHA1-AES256: 569.9Mbps • ESP-SHA256-AES256: 543.3Mbps • ESP-SHA384-AES256: 549.0Mbps • ESP-SHA512-AES256: 539.3Mbps |
| GRE | • Unencrypted: 967 Mbp • Encrypted: 616 Mbps |
| WireGuard VPN | 311.6Mbps |
| OpenVPN | 129.3Mbps |
| L2TP VPN Throughput | • Unencrypted: 909.4 Mbps • Encrypted: 494.9Mbps |
| PPTP VPN Throughput | • Unencrypted: 897.5 Mbps • Encrypted: 190.8 Mbps |
| SSL VPN Throughput | 126.7Mbps |
| DPI Throughput | • TCP: 881 Mbps • UDP: 813 Mbps |
| Omada App | Yes |
| Centralized Management | • Omada Central (Cloud-Based) • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Require the use of an Omada Controller. |
| Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
| Zero-Touch Provisioning | Yes. Require the use of an Omada Controller. |
| LAN DNS | √ |
| WAN Connection Type | • Static IP • Dynamic IP • PPPoE (supports MRU Configuration) • PPTP • L2TP |
| MAC Clone | Modify WAN Address |
| Stateful ACL | √ |
| Quality of Service | √ |
| Bridge VLAN | √ |
| mDNS Repeater | √ |
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| Bandwidth Control | IP-Based Bandwidth Control |
| Load Balance | • Intelligent Load Balance • Application Optimized Routing • Link Backup(Timing, Failover) • Online Detection |
| Session Limit | IP-Based Session Limit |
| System Requirements | • Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11 • MAC OS, NetWare, UNIX or Linux |
| Network Type | LTE Band of EU:• 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 (2100/1800/850/2600/ 900/800/700/1450 MHz• 4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz)• 3G DC-HSDPA/HSPA+/HSDPA/HSUPA/WCDMA: B1/B3/B5/B8 (2100/1800/850/900 MHz)Carrier Aggregation of EU:B1+B1/B3/B5/B7/B8/B20/B28/B38/B40/B41 B3+B3/B5/B7/B8/B20/B28/B38/B40/B41 B5+B5/B7/B38/B40/B41 B7+B7/B8/B20/B28/B32 B8+B32/B38/B40/B41 B20+B32/B38/B40 B28+B32/B38/B40/B41 B38+B38 B40+B40 B41+B41 |
| IPsec VPN | • 100 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm • IPsec Failover • IKE v1/v2 • MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS) |
| Standards and Protocols | IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE 802.3x, IEEE 802.1q, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP,L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP, 802.11a/b/g/n/ac/ax, LLDP |
| Interface | • 1× Gigabit WAN/LAN Port • 4× Gigabit LAN Ports • 1× DSL Port • 2× FXS Ports • 1× USB 3.0 (supports USB LTE dongle and USB Storage) • Dual-SIM Nano SIM Slot (4G+ Cat6) |
| Management Features | • Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration |
| DHCP | • DHCP Server • DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP • WAN DHCP 60 |
| Network Services Enabled by Default | Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP _____________________________________________________ TDP Server Device discovery • Port: 20003 Protocol: UDP _____________________________________________________ VOIP Server Monitor SIP messages • Port: 5060 Protocol: UDP _____________________________________________________ DHCP Server Handle DHCP packets • Port: 67 Protocol: UDP _____________________________________________________ DNS Handle DNS packets • Port: 53 Protocol: TCP/UDP |
| Environment | • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing |
PRODUCT DETAILS
Features and applications
DR3650v-4G at a glance
TP-Link DR3650v-4G is an enterprise router in the Business enterprise routers range. Use the model code when matching your deployment or replacement requirement.
- SIM Type: Dual-SIM Nano SIM Slot (4G+ Cat6)
- Cellular data rates: • Downlink: 300 Mbps; • Uplink: 50 Mbps
- Access Control: • Source/Destination IP Based ACL Stateful ACL • IPv4/IPv6 ACL • National Based ACL • FQDN
Configuration and installation
Match the WAN handoff, interface speeds and routing requirements to this model. Throughput varies with packet size, enabled services and software configuration.
Confirm hardware revision and included items in the quotation. A firmware-dependent feature or licensed capability must be checked against the actual configuration.
Related Business enterprise routers models
Ordering questions
What should I include in an enquiry?
Send DR3650v-4G with quantity, destination, required condition and any installation constraints. List power, optics or mounting accessories separately when required.
Are accessories and support included?
Inclusions depend on the exact ordering configuration. We confirm the supplied hardware, accessories and applicable commercial terms in writing.
Browse TP-Link equipment · Network equipment · Request a matched quotation
Prepare your enquiry
Ordering and delivery
Your existing equipment
Tell us the host model, generation, installed configuration and required supporting hardware.
Delivery requirements
Specify condition, testing requirements, destination and requested delivery date.
RELATED PRODUCTS
Related products and options
Check compatibility before choosing a replacement. The products below are related, but may not be interchangeable.
Browse this equipment range
Routers & WAN platforms
Branch connectivity, WAN aggregation and service-provider routing. Compare complete platforms separately from line cards and chassis components.
