TP-Link / Enterprise Router

TP-Link ER7212PC

Manufacturer P/N: ER7212PC

TP-Link ER7212PC enterprise router. IDS/IPS: Signature-based IPS/IDS threat detection; DPI: Deep Packet InspectionSupport 2421 type Applications; ACL: • Source/Destination IP Based ACL• Stateful ACL• IPv4/IPv6 ACL• National Based ACL• FQDN. Compare configuration and request a hardware quote.

Documented hardware version: V2.20; match the hardware revision before ordering
IDS/IPS: Signature-based IPS/IDS threat detection
DPI: Deep Packet InspectionSupport 2421 type Applications
ACL: • Source/Destination IP Based ACL• Stateful ACL• IPv4/IPv6 ACL• National Based ACL• FQDN

Price on request

Pricing, availability, condition, included options and warranty are confirmed in your quotation.

Help choosing compatible hardwareWorldwide delivery

CONNECTIONS & COMPATIBILITY

Network connections and supported equipment

Check the protocol and port requirements of the equipment you intend to connect. Ethernet, Fibre Channel, InfiniBand and carrier interfaces are not interchangeable.

CONNECTS TOClients, servers or access links

ER7212PCEnterprise Router

USED FORConnected network equipment

Connection and installation requirements

Port type, line rate, optics, reach and software license
Peer platform support, resiliency and management design

Storage connection examples ↗Servers & appliances ↗

Browse the product categories above for related equipment. Confirm compatibility with your full configuration before ordering.

Technical overview

Technical specifications

Use the complete part number when reviewing options and system requirements.

ER7212PC specifications
Manufacturer	TP-Link
Manufacturer part number	ER7212PC
Product family	Business enterprise routers
Documented hardware version	V2.20; match the hardware revision before ordering
IDS/IPS	Signature-based IPS/IDS threat detection
DPI	Deep Packet InspectionSupport 2421 type Applications
ACL	• Source/Destination IP Based ACL• Stateful ACL• IPv4/IPv6 ACL• National Based ACL• FQDN
DNS Proxy	DNSSEC, DoH, DoT, DNS Override
Filtering	URL Categoroies and URLs Filtering
Attack Defense	• TCP/UDP/ICMP Flood Defense• Block TCP Scan (Stealth FIN/Xmas/Null)• Block Ping from WAN
ARP Inspection	• Sending GARP Packets • IP-MAC Binding • ARP Detection
SSL VPN	80 Tunnels
PPTP VPN	• PPTP VPN Server • PPTP VPN Client (10) • 16 Tunnels • PPTP with MPPE Encryption
L2TP VPN	• L2TP VPN Server • L2TP VPN Client (10) • 16 Tunnels • L2TP over IPSec
OpenVPN	• OpenVPN Server • OpenVPN Client (10) • 16 OpenVPN Tunnels • "Certificate + Account" Mode • Full Mode
WireGuard VPN	√
Fan Quantity	Fanless
Button	Reset Button
Power Supply	53.5V DC/2.43A Adapter
PoE Budget	8× PoE+ Output Ports, 110 W PoE Budget
Flash	32Mbit Nor+8GB eMMC
DRAM	2 GB DDR4
Dimensions ( W x D x H )	8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)
Surge Protection	6 kV
Protection	6kV surge protection
Enclosure	Steel
Mounting	• Desktop • Wall-mount • Rack-mount (rackmount kit sold separately)
Max. Power Consumption	131 W (110 V/60 Hz) (With 110 W PD connected)
Concurrent Session	50,000
New Sessions /Second	3,800
NAT (Static IP)	940.2 Mbps / 947.5 Mbps
NAT(DHCP)	947.8 Mbps / 948.6 Mbps
NAT(PPPoE)	943.1 Mbps / 942.6 Mbps
NAT (L2TP)	898.4 Mbps / 915.8 Mbps
NAT (PPTP)	909.7 Mbps / 912.8 Mbps
66 Byte Packet Forwarding Rate	1,453,459 pps / 1,453,459 pps
1,518 Byte Packet forwarding rate	81,272 pps / 81,272 pps
IPsec VPN Throughput	• ESP-SHA1-AES256: 984.7 Mbps, ESP-SHA2-AES256: 990.5 Mbps, • ESP-SHA384-AES256: 983.9 Mbps, ESP-SHA512-AES256: 985.8 Mbps
WireGuard VPN	576.2 Mbps
OpenVPN	233.1 Mbps
L2TP VPN Throughput	• Unencrypted: 1,273.9 Mbps • Encrypted: 851.8 Mbps
PPTP VPN Throughput	• Unencrypted: 1293.5 Mbps • Encrypted: 297.1 Mbps
SSL VPN Throughput	243.1 Mbps
DPI Throughput	• TCP: 942 Mbps • UDP: 940 Mbps
IPS Throughput	• TCP: 939 Mbps • UDP: 936 Mbps
Omada App	Yes.
Centralized Management	Management of up to 24 Omada devices（2 gateway, 22 switches and EAPs in total）
Cloud Access	Yes.
Service	Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
Zero-Touch Provisioning	-
WAN Connection Type	• Static IP • Dynamic IP • PPPoE • PPTP • L2TP
MAC Clone	Modify WAN Address
DHCP	• DHCP Server • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP • WAN DHCP 60
Quality of Service	√
Bridge VLAN	√
mDNS Repeater	√
IPv6	StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
VLAN	802.1Q VLAN
IPTV	IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
Advanced Routing	• Static Routing • Policy Routing
Bandwidth Control	IP-based Bandwidth Control
Load Balance	• Intelligent Load Balance • Application Optimized Routing • Link Backup • Online Detection
NAT	• Multi-Net NAT • One-to-One NAT • Port Forwarding • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP • Disable NAT
Session Limit	IP-based Session Limit
Web Authentication	• No Authentication • Simple Password • Hotspot (Local User / Voucher/ SMS / Radius) • External Radius Sever • External Portal Sever
System Requirements	• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11 • MAC OS, NetWare, UNIX or Linux
IPsec VPN	• 20 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm • IPsec Failover • IKE v1/v2 • MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS)
Standards and Protocols	• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, SNMP, LLDP
Network Media	• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m)；EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m)；EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
Maintenance	• Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute) • NTP Synchronize • Port Mirroring • Syslog Support
Management Features	• Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration • OpenAPI
Environment	• Operating Temperature: -5 °C to 45 °C • Storage Temperature: -40 °C to 70 °C • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing

PRODUCT DETAILS

Features and applications

ER7212PC at a glance

TP-Link ER7212PC is an enterprise router in the Business enterprise routers range. Use the model code when matching your deployment or replacement requirement.

IDS/IPS: Signature-based IPS/IDS threat detection
DPI: Deep Packet InspectionSupport 2421 type Applications
ACL: • Source/Destination IP Based ACL• Stateful ACL• IPv4/IPv6 ACL• National Based ACL• FQDN

Configuration and installation

Match the WAN handoff, interface speeds and routing requirements to this model. Throughput varies with packet size, enabled services and software configuration.

Confirm hardware revision and included items in the quotation. A firmware-dependent feature or licensed capability must be checked against the actual configuration.
