Network Switch
Specify every connection
Cisco C9200L-24P-4G-E: 24 Gigabit PoE+ ports, 4 x 1G uplinks, Network Essentials. Request a configuration quote.
Tell us the configuration, quantity and destination. Your quotation will show availability, condition, warranty and delivery terms.
Start an order requestCisco / PRODUCT DETAILS
Start with the exact switch part number, then list every connection. Optics, uplink modules and software may be separate items.
List connected devices, link rates and their PoE requirements.
View all specifications →Cisco / ORDER & INSTALLATION DETAILS
Use the complete Cisco PID, including any bundle suffix.
Match the host platform and supported software release.
Identify separately ordered interfaces, optics, software and support.
Technical overview
Use the full part number when comparing options or asking about system fit.
| Base hardware model | C9200L-24P-4G |
|---|---|
| Downlink configuration | 24 x 10/100/1000 Mbps PoE+ copper ports |
| Uplink arrangement | 4 x 1G fixed uplinks |
| Network license tier | Network Essentials |
| Default primary PSU part number | PWR-C5-600WAC |
| Power supply serviceability | Field-replaceable power supplies |
| Cooling | Fixed redundant fans |
| Stacking bandwidth | 80 Gbps |
| PoE budget with one default primary PSU | 370 W |
| Product series | Catalyst C9200L-24P-4G |
| Manufacturer | Cisco |
| Model | Catalyst C9200L-24P-4G |
| Manufacturer P/N | C9200L-24P-4G-E |
| Product family | Cisco Campus Switch |
| Model / P/N | Cisco Catalyst C9200L-24P-4G / MPN C9200L-24P-4G-E |
| Category | Network Switch |
| Product reference | Manufacturer P/N C9200L-24P-4G-E, confirmed using the cited OEM documentation and professional product references. |
HOW THIS PRODUCT FITS YOUR NETWORK
Choose how you plan to use this product.
List connected devices, link rates and their PoE requirements.
C9200L-24P-4G-E: check access ports, uplinks and link rates.
This sketch helps describe your request. We will confirm protocols, port counts, coverage and failover when quoting.
YOUR QUOTE REQUEST
Add the quantity, options and installation details you want us to quote.
Specify the exact Cisco PID, software release and any required feature or throughput entitlement. Hardware and licenses are separate unless the quoted bundle states otherwise.
SUPPORT & REPLACEMENT
Check support dates, replacement options and whether continued use still makes sense.
We do not have confirmed sales and support dates for this part number.
Send us the full C9200L-24P-4G-E order code, software release and support details before planning long-term use.
Ask us to check the current sales and support statusProducts with similar names or connectors may still be incompatible. Compare the full specifications, installed system and software requirements.
Compare related products These products may be related, but we have not confirmed them as replacements.USING HARDWARE RESPONSIBLY
Consider repairability, remaining support and actual operating demand. Extending service life is useful only when the equipment still meets your security and reliability requirements.
Use measured average input power for the same workload. PSU ratings and processor TDP are different from total system power.
Energy difference = (current W − proposed W) × hours × units ÷ 1,000. Excludes cooling, embodied emissions and purchase costs.CONNECTION DETAILS
Check the protocol and port requirements of the equipment you intend to connect. Ethernet, Fibre Channel, InfiniBand and carrier interfaces are not interchangeable.
Browse the categories above for related equipment, then send us the full configuration so we can check the fit.
PRODUCT DETAILS
| Order line | Evidence to request | Keep explicit |
|---|---|---|
| Hardware PID | Full product identifier and revision | Chassis or component; quantity and physical variant |
| Operating software | Product family, release and intended features | Compatibility with the named hardware |
| Entitlement | License or service SKU and requested term | Account association and activation scope |
Network-system planning
| Decision | Information to provide | Impact on selection |
|---|---|---|
| Topology and role | Peer devices, connection map and required network role | Identifies the protocols and interoperability requirements to check. |
| Physical links | Port type, required link rate, connector and cable reach | Defines the optics or cabling review for both ends of each link. |
| Operating configuration | Airflow, power, software release, licenses and management needs | Resolves model suffixes, deployment fit and entitlement scope. |
PRODUCT PHOTOS
| P/N | Type | Tier | Term | Binding | SKU information |
|---|---|---|---|---|---|
| C9200L-DNA-E-24-3YCisco DNA Essentials | Feature subscription | Cisco DNA Essentials | 36 months | account | |
| C9200L-DNA-E-24-5YCisco DNA Essentials | Feature subscription | Cisco DNA Essentials | 60 months | account | |
| C9200L-DNA-E-24-7YCisco DNA Essentials | Feature subscription | Cisco DNA Essentials | 84 months | account |
Confirm protocol and feature support against the model documentation and your proposed network topology.
Map endpoint ports and uplinks, then confirm their documented capabilities for the exact switch and software release.
Validate each required VLAN, aggregation, routing or management feature separately. Feature support is specific to the model, software and license.
Confirm endpoint power requirements where PoE is used, and verify supported uplink modules and cabling.
Test the approved endpoint, uplink and redundancy design before site acceptance.
Compatibility and BOM checks
Model selection & order planning
Cisco Catalyst C9200L-24P-4G-E Switch
Confirm the supplied power arrangement, optics, license entitlement and any optional uplink module in the quotation. PoE output budgets, where listed, refer to the specified power configuration.
Explore more products below. Please confirm compatibility before selecting a replacement.
Before you request a quote
Include the full model, manufacturer P/N, revision and quantity.
Tell us the host model, generation, installed configuration and required supporting hardware.
Specify condition, testing requirements, destination and requested delivery date.
