Synology / NAS / SAN Storage
Synology DS1823xs+
Manufacturer P/N: DS1823xs+
Synology DS1823xs+ NAS / SAN Storage. cpu model: AMD Ryzen V1780B; cpu quantity: 1; cpu cores: 4. Request pricing and a matched configuration from Star Networking.
- Model / part number
- DS1823xs+
- CPU Model
- AMD Ryzen V1780B
- CPU Quantity
- 1
- CPU Cores
- 4
$2,457.99 USD · Condition confirmed with quotation
Synology DS1823XS+, diskless standard configuration. Data drives and optional upgrades are quoted separately.
Contact us to confirm availability. Final price, shipping and taxes are confirmed before payment.
Pricing, availability, condition, included options and warranty are confirmed in your quotation.
Help choosing compatible hardwareWorldwide delivery
STORAGE & SAN
Storage systems
and SAN solutions
Compare storage arrays, servers and switches for Fibre Channel, iSCSI and file storage. Select a system below to see its connections and ordering considerations.
View storage connection examplesCONNECTIONS / 10GbE / backup traffic
Synology backup storage over 10GbE
Star Networking connection example · component-based design
SHOW CONNECTIONS
Select a product to see how it connects
Swipe to explore the full hardware map →
01 SERVERS
02 NETWORK
03 STORAGE
Logical data paths. Images show the equipment; cable endpoints are not physical port locations.
Backup protection · single network path01
Select and protect supported workloads.
02
Write backups to a dedicated NAS repository.
03
Replicate a recovery copy away from the primary site.
A separate backup network connects supported server workloads to a Synology repository. Add an off-site copy to protect against a site-wide incident.
Confirm the full configuration and compatibility before ordering.Synology · backup: equipment and connection requirements＋
A separate backup network connects supported server workloads to a Synology repository. Add an off-site copy to protect against a site-wide incident.
Dell PowerEdge R750 ↗Workstations & VMs ↗NETGEAR XS508M ↗Synology DS1823xs+ ↗Off-site backup target ↗
- This is a proposed connection example, not a jointly certified hardware bundle. Confirm NIC, operating system and backup-package support.
- One switch and one NAS uplink remain single points of failure. An off-site copy is a recovery layer, not automatic network failover.
- Size retention, change rate and restore time before selecting drive capacity. Test restoration rather than relying only on successful backup jobs.
Star Networking connection example · component-based design
Technical overview
Technical specifications
Use the complete part number when reviewing options and system requirements.
| Manufacturer | Synology |
|---|---|
| Model / part number | DS1823xs+ |
| CPU Model | AMD Ryzen V1780B |
| CPU Quantity | 1 |
| CPU Cores | 4 |
| CPU Threads | 8 |
| CPU Architecture | 64-bit |
| CPU Frequency | 3.35 (base) / 3.6 (turbo) GHz |
| Hardware Encryption Engine | Supported |
| System Memory | 8 GB DDR4 ECC SODIMM |
| Memory Module Pre-installed | 8 GB (8 GB × 1) |
| Total Memory Slots | 2 |
| Maximum Memory Capacity | 32 GB (16 GB × 2) |
| Drive Bays | 8 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD |
| Maximum Drive Bays with Expansion Unit | 18 (DX517 × 2) |
| RJ-45 1GbE LAN Port | 2 |
| RJ-45 10GbE LAN Port | 1 |
| Out-of-Band Management LAN Port | 1 |
| USB 3.2 Gen 1 Port | 3 |
| Expansion Port | 2 |
| Expansion Port Type | eSATA |
| PCIe Expansion | 1 × Gen3 x8 slot (x4 link) |
| Size (Height × Width × Depth) | 166 mm × 343 mm × 243 mm |
| Weight | 6.2 kg |
| System Fan | 120 mm × 120 mm × 2 pcs |
| Fan Speed Mode | Full-Speed Mode Cool Mode Quiet Mode |
| Easy Replacement System Fan | Supported |
| Brightness Adjustable Front LED Indicators | Supported |
| Power Recovery | Supported |
| Scheduled Power On / Off | Supported |
| Wake on LAN / WAN | Supported |
| Power Supply Unit / Adapter | 250 watts |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Operating Humidity | 8% to 80% RH |
| Storage Humidity | 5% to 95% RH |
PRODUCT DETAILS
Features and applications
DS1823xs+ configuration overview
Synology DS1823xs+ NAS / SAN Storage. cpu model: AMD Ryzen V1780B; cpu quantity: 1; cpu cores: 4. Request pricing and a matched configuration from Star Networking.
Order against the exact part number. A chassis, expansion enclosure and upgrade component are different products; installed drives and optional modules must be specified in the quotation.
Deployment planning
Confirm the workload, usable capacity, network connectivity and power requirements before selecting options. An expansion connector is not automatically compatible with every enclosure. Keep an independent backup appropriate to your recovery requirements.
Matched memory options
Request a matched quotation
Send the model, quantity, required drives or upgrades, and destination. We will quote the configuration and confirm included items, condition and commercial terms.
Prepare your enquiry
Ordering and delivery
Model and quantity
Include the full model, manufacturer P/N, revision and quantity.
Your existing equipment
Tell us the host model, generation, installed configuration and required supporting hardware.
Delivery requirements
Specify condition, testing requirements, destination and requested delivery date.
